Signed-off-by: Pedro Demarchi Gomes <pedrodemargomes@gmail.com>
---
 tools/testing/selftests/vm/ksm_tests.c | 40 +++++++++++++++++++-------
 1 file changed, 30 insertions(+), 10 deletions(-)

diff --git a/tools/testing/selftests/vm/ksm_tests.c b/tools/testing/selftests/vm/ksm_tests.c
index b61dcdb44c5b..92b716565d9c 100644
--- a/tools/testing/selftests/vm/ksm_tests.c
+++ b/tools/testing/selftests/vm/ksm_tests.c
@@ -5,6 +5,7 @@
 #include <time.h>
 #include <string.h>
 #include <numa.h>
+#include <err.h>

 #include "../kselftest.h"
 #include "../../../../include/vdso/time64.h"
@@ -34,7 +35,8 @@ enum ksm_test_name {
        CHECK_KSM_ZERO_PAGE_MERGE,
        CHECK_KSM_NUMA_MERGE,
        KSM_MERGE_TIME,
-       KSM_COW_TIME
+       KSM_COW_TIME,
+       KSM_MERGE_TIME_HUGE_PAGES
 };

 static int ksm_write_sysfs(const char *file_path, unsigned long val)
@@ -99,6 +101,9 @@ static void print_help(void)
               " -U (page unmerging)\n"
               " -P evaluate merging time and speed.\n"
               "    For this test, the size of duplicated memory area (in MiB)\n"
+              "    must be provided using -s option\n"
+                  " -H evaluate merging time and speed of huge pages.\n"
+              "    For this test, the size of duplicated memory area (in MiB)\n"
               "    must be provided using -s option\n"
               " -C evaluate the time required to break COW of merged pages.\n\n");

@@ -118,10 +123,14 @@ static void print_help(void)
        exit(0);
 }

-static void  *allocate_memory(void *ptr, int prot, int mapping, char data, size_t map_size)
+static void  *allocate_memory(void *ptr, int prot, int mapping, char data, size_t map_size,
+                                bool huge_page)
 {
        void *map_ptr = mmap(ptr, map_size, PROT_WRITE, mapping, -1, 0);

+       if (huge_page && madvise(map_ptr, map_size, MADV_HUGEPAGE))
+               err(2, "MADV_HUGEPAGE");
+
        if (!map_ptr) {
                perror("mmap");
                return NULL;
@@ -250,7 +259,7 @@ static int check_ksm_merge(int mapping, int prot, long page_count, int timeout,
        }

        /* fill pages with the same data and merge them */
-       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count);
+       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count, false);
        if (!map_ptr)
                return KSFT_FAIL;

@@ -282,7 +291,7 @@ static int check_ksm_unmerge(int mapping, int prot, int timeout, size_t page_siz
        }

        /* fill pages with the same data and merge them */
-       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count);
+       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count, false);
        if (!map_ptr)
                return KSFT_FAIL;

@@ -325,7 +334,7 @@ static int check_ksm_zero_page_merge(int mapping, int prot, long page_count, int
                return KSFT_FAIL;

        /* fill pages with zero and try to merge them */
-       map_ptr = allocate_memory(NULL, prot, mapping, 0, page_size * page_count);
+       map_ptr = allocate_memory(NULL, prot, mapping, 0, page_size * page_count, false);
        if (!map_ptr)
                return KSFT_FAIL;

@@ -416,7 +425,7 @@ static int check_ksm_numa_merge(int mapping, int prot, int timeout, bool merge_a
        return KSFT_FAIL;
 }

-static int ksm_merge_time(int mapping, int prot, int timeout, size_t map_size)
+static int ksm_merge_time(int mapping, int prot, int timeout, size_t map_size, bool huge_page)
 {
        void *map_ptr;
        struct timespec start_time, end_time;
@@ -424,7 +433,7 @@ static int ksm_merge_time(int mapping, int prot, int timeout, size_t map_size)

        map_size *= MB;

-       map_ptr = allocate_memory(NULL, prot, mapping, '*', map_size);
+       map_ptr = allocate_memory(NULL, prot, mapping, '*', map_size, huge_page);
        if (!map_ptr)
                return KSFT_FAIL;

@@ -466,7 +475,7 @@ static int ksm_cow_time(int mapping, int prot, int timeout, size_t page_size)
        /* page_count must be less than 2*page_size */
        size_t page_count = 4000;

-       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count);
+       map_ptr = allocate_memory(NULL, prot, mapping, '*', page_size * page_count, false);
        if (!map_ptr)
                return KSFT_FAIL;

@@ -541,7 +550,7 @@ int main(int argc, char *argv[])
        bool merge_across_nodes = KSM_MERGE_ACROSS_NODES_DEFAULT;
        long size_MB = 0;

-       while ((opt = getopt(argc, argv, "ha:p:l:z:m:s:MUZNPC")) != -1) {
+       while ((opt = getopt(argc, argv, "ha:p:l:z:m:s:MUZNPCH")) != -1) {
                switch (opt) {
                case 'a':
                        prot = str_to_prot(optarg);
@@ -598,6 +607,9 @@ int main(int argc, char *argv[])
                case 'C':
                        test_name = KSM_COW_TIME;
                        break;
+               case 'H':
+                       test_name = KSM_MERGE_TIME_HUGE_PAGES;
+                       break;
                default:
                        return KSFT_FAIL;
                }
@@ -645,12 +657,20 @@ int main(int argc, char *argv[])
                        return KSFT_FAIL;
                }
                ret = ksm_merge_time(MAP_PRIVATE | MAP_ANONYMOUS, prot, ksm_scan_limit_sec,
-                                    size_MB);
+                                    size_MB, false);
                break;
        case KSM_COW_TIME:
                ret = ksm_cow_time(MAP_PRIVATE | MAP_ANONYMOUS, prot, ksm_scan_limit_sec,
                                   page_size);
                break;
+       case KSM_MERGE_TIME_HUGE_PAGES:
+               if (size_MB == 0) {
+                       printf("Option '-s' is required.\n");
+                       return KSFT_FAIL;
+               }
+               ret = ksm_merge_time(MAP_PRIVATE | MAP_ANONYMOUS, prot, ksm_scan_limit_sec,
+                                    size_MB, true);
+               break;
        }

        if (ksm_restore(&ksm_sysfs_old)) {
--
2.25.1

Add test case of KSM merging time using mostly huge pages

Signed-off-by: Pedro Demarchi Gomes <pedrodemargomes@gmail.com>
---
 tools/testing/selftests/vm/ksm_tests.c | 125 ++++++++++++++++++++++++-
 1 file changed, 124 insertions(+), 1 deletion(-)

diff --git a/tools/testing/selftests/vm/ksm_tests.c b/tools/testing/selftests/vm/ksm_tests.c
index b61dcdb44c5b..61f3360a19df 100644
--- a/tools/testing/selftests/vm/ksm_tests.c
+++ b/tools/testing/selftests/vm/ksm_tests.c
@@ -5,6 +5,10 @@
 #include <time.h>
 #include <string.h>
 #include <numa.h>
+#include <unistd.h>
+#include <fcntl.h>
+#include <stdint.h>
+#include <err.h>

 #include "../kselftest.h"
 #include "../../../../include/vdso/time64.h"
@@ -18,6 +22,15 @@
 #define KSM_MERGE_ACROSS_NODES_DEFAULT true
 #define MB (1ul << 20)

+#define PAGE_SHIFT 12
+#define HPAGE_SHIFT 21
+
+#define PAGE_SIZE (1 << PAGE_SHIFT)
+#define HPAGE_SIZE (1 << HPAGE_SHIFT)
+
+#define PAGEMAP_PRESENT(ent)	(((ent) & (1ull << 63)) != 0)
+#define PAGEMAP_PFN(ent)	((ent) & ((1ull << 55) - 1))
+
 struct ksm_sysfs {
 	unsigned long max_page_sharing;
 	unsigned long merge_across_nodes;
@@ -34,6 +47,7 @@ enum ksm_test_name {
 	CHECK_KSM_ZERO_PAGE_MERGE,
 	CHECK_KSM_NUMA_MERGE,
 	KSM_MERGE_TIME,
+	KSM_MERGE_TIME_HUGE_PAGES,
 	KSM_COW_TIME
 };

@@ -99,6 +113,9 @@ static void print_help(void)
 	       " -U (page unmerging)\n"
 	       " -P evaluate merging time and speed.\n"
 	       "    For this test, the size of duplicated memory area (in MiB)\n"
+	       "    must be provided using -s option\n"
+				 " -H evaluate merging time and speed of area allocated mostly with huge pages\n"
+	       "    For this test, the size of duplicated memory area (in MiB)\n"
 	       "    must be provided using -s option\n"
 	       " -C evaluate the time required to break COW of merged pages.\n\n");

@@ -416,6 +433,101 @@ static int check_ksm_numa_merge(int mapping, int prot, int timeout, bool merge_a
 	return KSFT_FAIL;
 }

+int64_t allocate_transhuge(void *ptr, int pagemap_fd)
+{
+	uint64_t ent[2];
+
+	/* drop pmd */
+	if (mmap(ptr, HPAGE_SIZE, PROT_READ | PROT_WRITE,
+				MAP_FIXED | MAP_ANONYMOUS |
+				MAP_NORESERVE | MAP_PRIVATE, -1, 0) != ptr)
+		errx(2, "mmap transhuge");
+
+	if (madvise(ptr, HPAGE_SIZE, MADV_HUGEPAGE))
+		err(2, "MADV_HUGEPAGE");
+
+	/* allocate transparent huge page */
+	*(volatile void **)ptr = ptr;
+
+	if (pread(pagemap_fd, ent, sizeof(ent),
+			(uintptr_t)ptr >> (PAGE_SHIFT - 3)) != sizeof(ent))
+		err(2, "read pagemap");
+
+	if (PAGEMAP_PRESENT(ent[0]) && PAGEMAP_PRESENT(ent[1]) &&
+	    PAGEMAP_PFN(ent[0]) + 1 == PAGEMAP_PFN(ent[1]) &&
+	    !(PAGEMAP_PFN(ent[0]) & ((1 << (HPAGE_SHIFT - PAGE_SHIFT)) - 1)))
+		return PAGEMAP_PFN(ent[0]);
+
+	return -1;
+}
+
+static int ksm_merge_hugepages_time(int mapping, int prot, int timeout, size_t map_size)
+{
+	void *map_ptr, *map_ptr_orig;
+	struct timespec start_time, end_time;
+	unsigned long scan_time_ns;
+	int pagemap_fd, n_normal_pages, n_huge_pages;
+
+	map_size *= MB;
+	size_t len = map_size;
+
+	len -= len % HPAGE_SIZE;
+	map_ptr_orig = mmap(NULL, len + HPAGE_SIZE, PROT_READ | PROT_WRITE,
+			MAP_ANONYMOUS | MAP_NORESERVE | MAP_PRIVATE, -1, 0);
+	map_ptr = map_ptr_orig + HPAGE_SIZE - (uintptr_t)map_ptr_orig % HPAGE_SIZE;
+
+	if (map_ptr_orig == MAP_FAILED)
+		err(2, "initial mmap");
+
+	if (madvise(map_ptr, len + HPAGE_SIZE, MADV_HUGEPAGE))
+		err(2, "MADV_HUGEPAGE");
+
+	pagemap_fd = open("/proc/self/pagemap", O_RDONLY);
+	if (pagemap_fd < 0)
+		err(2, "open pagemap");
+
+	n_normal_pages = 0;
+	n_huge_pages = 0;
+	for (void *p = map_ptr; p < map_ptr + len; p += HPAGE_SIZE) {
+		if (allocate_transhuge(p, pagemap_fd) < 0)
+			n_normal_pages++;
+		else
+			n_huge_pages++;
+	}
+	printf("Number of normal pages:    %d\n", n_normal_pages);
+	printf("Number of huge pages:    %d\n", n_huge_pages);
+
+	memset(map_ptr, '*', len);
+
+	if (clock_gettime(CLOCK_MONOTONIC_RAW, &start_time)) {
+		perror("clock_gettime");
+		goto err_out;
+	}
+	if (ksm_merge_pages(map_ptr, map_size, start_time, timeout))
+		goto err_out;
+	if (clock_gettime(CLOCK_MONOTONIC_RAW, &end_time)) {
+		perror("clock_gettime");
+		goto err_out;
+	}
+
+	scan_time_ns = (end_time.tv_sec - start_time.tv_sec) * NSEC_PER_SEC +
+		       (end_time.tv_nsec - start_time.tv_nsec);
+
+	printf("Total size:    %lu MiB\n", map_size / MB);
+	printf("Total time:    %ld.%09ld s\n", scan_time_ns / NSEC_PER_SEC,
+	       scan_time_ns % NSEC_PER_SEC);
+	printf("Average speed:  %.3f MiB/s\n", (map_size / MB) /
+					       ((double)scan_time_ns / NSEC_PER_SEC));
+
+	munmap(map_ptr_orig, len + HPAGE_SIZE);
+	return KSFT_PASS;
+
+err_out:
+	printf("Not OK\n");
+	munmap(map_ptr_orig, len + HPAGE_SIZE);
+	return KSFT_FAIL;
+}
+
 static int ksm_merge_time(int mapping, int prot, int timeout, size_t map_size)
 {
 	void *map_ptr;
@@ -541,7 +653,7 @@ int main(int argc, char *argv[])
 	bool merge_across_nodes = KSM_MERGE_ACROSS_NODES_DEFAULT;
 	long size_MB = 0;

-	while ((opt = getopt(argc, argv, "ha:p:l:z:m:s:MUZNPC")) != -1) {
+	while ((opt = getopt(argc, argv, "ha:p:l:z:m:s:MUZNPCH")) != -1) {
 		switch (opt) {
 		case 'a':
 			prot = str_to_prot(optarg);
@@ -595,6 +707,9 @@ int main(int argc, char *argv[])
 		case 'P':
 			test_name = KSM_MERGE_TIME;
 			break;
+		case 'H':
+			test_name = KSM_MERGE_TIME_HUGE_PAGES;
+			break;
 		case 'C':
 			test_name = KSM_COW_TIME;
 			break;
@@ -647,6 +762,14 @@ int main(int argc, char *argv[])
 		ret = ksm_merge_time(MAP_PRIVATE | MAP_ANONYMOUS, prot, ksm_scan_limit_sec,
 				     size_MB);
 		break;
+	case KSM_MERGE_TIME_HUGE_PAGES:
+		if (size_MB == 0) {
+			printf("Option '-s' is required.\n");
+			return KSFT_FAIL;
+		}
+		ret = ksm_merge_hugepages_time(MAP_PRIVATE | MAP_ANONYMOUS, prot,
+				ksm_scan_limit_sec, size_MB);
+		break;
 	case KSM_COW_TIME:
 		ret = ksm_cow_time(MAP_PRIVATE | MAP_ANONYMOUS, prot, ksm_scan_limit_sec,
 				   page_size);
--
2.25.1
